6 SECTION WIDTH BOX
The section width box can be used to operate the section width circuit and the spray On/Off
function.
It is connected to the terminal and consists - among other things - of a display, a switch and
LED displays.
The section width box is connected to an LIN port on the terminal.
6.1 Overview
Key Function
Light emitting diode
Status display
Spray on/off
Section width switches 1 -
9
6.2 Function
As soon as the section width box is connected to the terminal, the keys 1 to 9 on the terminal's
section width circuit are deactivated.
The spray On/Off function can be operated using both the terminal and the section width box.
Spray
on/off
Section
width
switch
Status
display
Light emitting
diode
