Extending and retracting SE linkage
29
9.3.2 Extending the linkage symmetrically
- Press the key to select the function extend linkage symmetrically.
The extend linkage symmetrically menu now appears.
The linkage can be extended symmetrically as follows:
Boom 1
Booms 2 + 3
Boom 4
- Raise the linkage, using the tractor's corresponding control unit, until the folding position is
reached.
The Pendulum lock display is now shown.
- Close the pendulum lock.
