Extending and retracting SE linkage
40
The second Fold-in linkage asymmetrically menu now appears.
The linkage can be extended asymmetrically as follows:
Booms 2 + 3 – left
Slope compensation
Booms 2 + 3 - right
- Press the key to preselect booms 2 and 3 - left.
- Press and hold the key, any information is then displayed.
To fold-in booms 2 + 3 - left:
- Operate the tractor's corresponding control unit.
- Press the key or another function key to cancel the preselection.
- Press the key to preselect booms 2 and 3 - right.
- Press and hold the key, any information is then displayed.
To fold-in booms 2 + 3 - right:
- Operate the tractor's corresponding control unit.
- Press the key or another function key to cancel the preselection.
- Press one of the keys to preselect the slope compensation.
To set the slope compensation:
- Operate the tractor's corresponding control unit.
