Lenovo ThinkServer TD230 Hardware Maintenance Manual

Chapter4.Locatingparts,controls,LEDs,andconnectors
Thischapterprovidesinformationtohelpyoulocateyourserverparts,controls,light-emittingdiodes
(LEDs),andconnectors.
Frontview
Figure1“Frontviewoftheserver”onpage27showstheLEDsandpartsonthefrontoftheserver.
Figure1.Frontviewoftheserver
1PowerLED
4SystemstatusLED
2HarddiskdrivestatusLED5Frontdoorlock
3EthernetstatusLED6Logoplate
Youcanopenthefrontdoorwiththekeytolocatecontrols,LEDs,connectors,andotherpartsonthe
frontpanel.
©CopyrightLenovo2010,2011
27
