Lenovo ThinkServer TD230 Hardware Maintenance Manual

Figure6.Servercomponentlocations(sideviewwithouttheservercover)
1Powersupplyassembly
9OnboardICH10RSATARAIDcontroller
2Memoryslotsformicroprocessor1(some
slotsmightwithinstalledmemorymodules)
10PCIExpressx4slot
3Opticaldrive11PCIcardslot
4Harddiskdrivezone*
12PCIExpressx8slots(3)
5Systemfan213Heatsinkandfanassembly(microprocessor1underneath)
6Systemfan114Rearfan(systemfan3)
7Microprocessor2socket(thesecond
microprocessorisoptional)
15Systemboardbattery
8Memoryslotsformicroprocessor2(some
slotsmightwithinstalledmemorymodules)
16Systemboard
Note:*denotesthatthisillustrationonlyshowstheservermodelswithfourhot-swapharddiskdrives.Thereare
alsoservermodelsthatsupportuptovenon-hot-swapharddiskdrives.
Locatingpartsonthesystemboard
Figure7“Locatingmajorpartsonthesystemboard”onpage34showsthelocationsofthemajorparts
onthesystemboard.
Chapter4.Locatingparts,controls,LEDs,andconnectors33
