Figure4.Rearviewoftheserver
1Powercordconnector
5PCIcardzone
2Serialport
6Ethernetconnector2
3VGAmonitorconnector
7Ethernetconnector1
4USBconnectors(4)8Frontdoorkey(cuttheplasticcliptogetthekey)
Hot-swapharddiskdrivestatusLEDs
Forservermodelswithhot-swapharddiskdrives,eachhot-swapharddiskdrivealsohastwostatus
LEDsonthefront.
Figure5.Hot-swapharddiskdrivestatusLEDs
Chapter4.Locatingparts,controls,LEDs,andconnectors31
