Lenovo ThinkServer TD230 Hardware Maintenance Manual

16Memoryslot(CPU2DIMMCHE2)33Systemboardbattery
17Memoryslot(CPU2DIMMCHE1)34Systemfan3connector
LocatingdiagnosticLEDsonthesystemboard
ThereareseveraldiagnosticLEDsonthesystemboardtohelpyoudiagnosespecicproblems.Figure
8“DiagnosticLEDsonthesystemboard”onpage35showsthelocationsofthediagnosticLEDson
thesystemboard.
Figure8.DiagnosticLEDsonthesystemboard
1HarddiskdriveLED
7Microprocessor2heatsinkfanfaultLED
2Systemfan3faultLED8Systemfan1faultLED
35VSBLED9DIMMfaultLEDs(4)
4DIMMfaultLEDs(4)
10Post-codediagnosticLEDs
5Systemfan2faultLED11StatusLED
6Microprocessor1heatsinkfanfaultLED
12SystemIDLED
Jumperblocksettings
Thereareseveraljumperblocksonthesystemboardthatcanbeusedtocongure,recover,or
enable/disablespecicfeaturesoftheserversystemboard.Figure9“Jumperblocksonthesystemboard”
onpage36
showsthestatusofthejumperblocksonthesystemboard.
Chapter4.Locatingparts,controls,LEDs,andconnectors35
