Thefollowingillustrationshowsthelocationsofallmemoryslotsonasystemboardthathastwo
microprocessors(alsoknownasCPUs)installed.
Figure43.Memoryslotsonthesystemboard
1Memoryslot(CPU1DIMMA1)7Memoryslot(CPU2DIMMD1)
2Memoryslot(CPU1DIMMA2)8Memoryslot(CPU2DIMMD2)
3Memoryslot(CPU1DIMMB1)9Memoryslot(CPU2DIMME1)
4Memoryslot(CPU1DIMMB2)10Memoryslot(CPU2DIMME2)
5Memoryslot(CPU1DIMMC1)11Memoryslot(CPU2DIMMF1)
6Memoryslot(CPU1DIMMC2)12Memoryslot(CPU2DIMMF2)
Thefollowingtableexplainsthememorymoduleinstallationrulesforserversthathaveonlyone
microprocessor(CPU1)installed.The“X”markindicatesthememoryslotsintowhichthememorymodules
shouldbeinstalledindifferentsituations.
Note:Ensurethatyouobservertheinstallationguidelinesatthebeginningofthistopic.
Figure44.CPU1DIMMs
