Table5.Memorymoduleinstallationrulesforserverswithonemicroprocessor
CPU1DIMM
A1A2B1B2
C1C2
OneDIMM
X
TwoDIMMsXX
ThreeDIMMsXXX
FourDIMMsXXXX
SixDIMMs
XXXXXX
Thefollowingtableexplainsthememorymoduleinstallationrulesforserversthathavetwomicroprocessors
(CPU1andCPU2)installed.The“X”markindicatesthememoryslotsintowhichthememorymodules
shouldbeinstalledindifferentsituations.
Note:Ensurethatyouobservertheinstallationguidelinesatthebeginningofthistopic.
Figure45.CPU1DIMMsandCPU2DIMMs
Table6.Memorymoduleinstallationrulesforserverswithtwomicroprocessors
CPU1DIMMCPU2DIMM
A1A2B1B2
C1C2
D1D2E1E2F1F2
TwoDIMMsXX
FourDIMMsXXXX
SixDIMMs
XXXXXX
EightDIMMsXXXXXXXX
TwelveDIMMsXXXXXXXXXXXX
Thefollowingsectionexplainsthememorymoduleinstallationrulesinindependentmode,mirroringmode,
sparingmode,andlockstepmode.
Chapter6.Installing,removing,orreplacinghardware95
