SomeservermodelscomewitharequiredRAIDcardtoprovideadvancedSATA/SAShardwareRAID
functions.IfyourserverdoesnotcomewithaRAIDcard,youcanpurchaseonefromLenovo.
Note:TheoptionkitfortheRAIDcardisdesignedfordifferenttypesofserversandmightcontainadditional
cablesthatarenotrequiredforyourserver.
Ifyourserverhasonemicroprocessorinstalled,itisrecommendedthattheRAIDcardbeinstalledintothe
PCI-Eslot5orPCI-Eslot2.Ifyourserverhastwomicroprocessorsinstalled,itisrecommendedthatthe
RAIDcardbeinstalledintothePCI-Eslot4.See“InstallingorremovingtheRAIDcard”onpage104
and
“Systemboardcomponents”onpage48.
YourserversupportsthefollowingRAIDcards:
•ThinkServerRAID500Adapter(alsoknownasThinkServer9240-8iRAID0/1Adapter)
•ThinkServerRAID700Adapter(alsoknownasThinkServer9260-8iSASRAIDAdapter)
•ThinkServerRAID710Adapter(alsoknownas9270CV-8iRAIDadapter)
ThinkServerRAID500Adapter(alsoknownasThinkServer9240-8iRAID0/1Adapter)
ThefollowingillustrationshowstheconnectorsontheThinkServerRAID500Adapter.
Figure17.ThinkServerRAID500Adapter
1Port0
3ThinkServerRAID500UpgradeKeyforAdvancedRAID
connector
2Port14Externalconnector
1Port0
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage43
.
2Port1
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage43
.
3ThinkServerRAID500UpgradeKeyforAdvancedRAIDconnector
UsedtoconnectaThinkServerRAID500UpgradeKeyforAdvancedRAID.See“Installingorremovingthe
ThinkServerRAID500UpgradeKeyforAdvancedRAID”onpage107
.
