4Externalconnector
UsedtoattachthecablethatconnectsaRAIDcardtothesystemboardharddiskdriveLEDconnector.See
“Connectingthecables”onpage43.
ThinkServerRAID700Adapter(alsoknownasThinkServer9260-8iSASRAIDAdapter)
ThefollowingillustrationshowstheconnectorsontheThinkServerRAID700Adapter.
Figure18.ThinkServerRAID700Adapter
1Ports7-43Externalconnector
2Ports3-0
4ThinkServerRAID700Batteryconnector
1Ports7-4
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage43.
2Ports3-0
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage43
.
3Externalconnector
UsedtoattachthecablethatconnectsaRAIDcardtothesystemboardharddiskdriveLEDconnector.See
“Connectingthecables”onpage43.
4ThinkServerRAID700Batteryconnector
UsedtoconnectaThinkServerRAID700Battery.See“InstallingorremovingtheThinkServerRAID700
Battery”onpage109.
Chapter3.Productoverview37
