2.5-inchhot-swaphard-disk-drivebackplane
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthe2.5-inchhot-swaphard-disk-drive
backplane.
Thefollowingillustrationsshowtheconnectorsonthe2.5-inchhot-swaphard-disk-drivebackplane.
Figure24.Frontviewofthe2.5-inchhot-swaphard-disk-drivebackplane
1Slot0fora2.5-inchSAShot-swapharddisk
drive
5Slot4fora2.5-inchSAShot-swapharddiskdrive
2Slot1fora2.5-inchSAShot-swapharddisk
drive
6Slot5fora2.5-inchSAShot-swapharddiskdrive
3Slot2fora2.5-inchSAShot-swapharddisk
drive
7Slot6fora2.5-inchSAShot-swapharddiskdrive
4Slot3fora2.5-inchSAShot-swapharddisk
drive
8Slot7fora2.5-inchSAShot-swapharddiskdrive
Figure25.Rearviewofthe2.5-inchhot-swaphard-disk-drivebackplane
18-pinpowerconnector
UsedtoconnecttheP5powerconnectorofthepowersupply.
