5.Pressthereleasetab1asshownandpivotthedrivebayassemblyupward.
Figure92.Pivotingthedrivebayassemblyupward
6.Recordthecableroutingandcableconnections.Then,disconnectthepowersupplyassemblycables
fromalldrivesandfromthesystemboard.See“Partsonthesystemboard”onpage34.
7.Releasethepowersupplyassemblycablesfromanycableclipsorties.
Chapter9.Installingorreplacinghardware141
