Lenovo ThinkSystem SR860 V2 - Page 107

16i + 16i + 16i RAID adapters
SAS/SATA cable routing PCIe cable routing
Length
To
NVMe
connector
Length
To
1
665 mm
C0 (16i)
1 0-1, 2-3 530 mm
PCIe 3 (tray)
2
860 mm
C1 (16i)
2 4-5, 6-7 670 mm
PCIe 6 (tray)
3
1000 mm
C0 (16i)
4
665 mm
C1 (16i)
5
820 mm
6
• Gen3: 930 mm
• Gen4: 945 mm
Chapter 3. Internal cable routing 99
