Lenovo ThinkSystem SR860 V2 Setup Guide

Table 1. Specifications, Type 7Z59 and 7Z60 (continued)
Expansion slots Up to seventeen slots:
• Slot 1 to 4 (4U PCIe riser cage):
– PCI Express 3.0 x8 (Slot 1, 2, 3, 4) or
– PCI Express 3.0 x16 (Slot 2, 4)
• Slot 5 to 7 (PCIe riser card):
– PCI Express 3.0 x16 (Slot 5, 6, 7) or
– PCI Express 3.0 x8 (Slot 5, 6)
• Slot 8 (OCP 3.0 Ethernet adapter)
• Slot 9 to 12 (4U PCIe riser cage):
– PCI Express 3.0 x8 (Slot 9, 10, 11, 12) or
– PCI Express 3.0 x16 (Slot 10, 12)
• Slot 13: PCI Express 3.0 x16
• Slot 14: PCI Express 3.0 x8
• Slot 15: PCI Express 3.0 x8
• Slot 16 to 17: 7mm/M.2 drive bays
Integrated functions • Lenovo XClarity Controller (XCC), which provides service processor control and
monitoring functions, video controller, and remote keyboard, video, mouse, and
remote drive capabilities.
• One system-management RJ-45 connector on the rear to connect to a systems-
management network. This connector is dedicated to the Lenovo XClarity Controller
functions and runs at 1 GB speed.
• Four universal serial bus (USB) ports:
– Two on the front of the server:
– One USB 2.0 with Lenovo XClarity Controller management
– One USB 3.1
– Two USB 3.1 on the rear of the server
• One serial port
RAID adapter
(depending on model)
The following options with support for RAID levels 0, 1, and 10 are available for this
server with up to four flash power modules:
• ThinkSystem 430-8i SAS/SATA 12Gb HBA
• ThinkSystem 430-16i SAS/SATA 12Gb HBA
• ThinkSystem 430-8e SAS/SATA 12Gb HBA
• ThinkSystem 430-16e SAS/SATA 12Gb HBA
• ThinkSystem RAID 530-8i PCIe 12Gb Adapter
• ThinkSystem RAID 530-16i PCIe 12Gb Adapter
• ThinkSystem RAID 930-8i 2GB Flash PCIe 12Gb Adapter
• ThinkSystem RAID 930-16i 4GB Flash PCIe 12Gb Adapter
• ThinkSystem RAID 930-8e 4GB Flash PCIe 12Gb Adapter
• ThinkSystem RAID 940-8i 4GB Flash PCIe Gen4 12Gb Adapter
• ThinkSystem RAID 940-8i 8GB Flash PCIe Gen4 12Gb Adapter
• ThinkSystem RAID 940-16i 4GB Flash PCIe 12Gb Adapter
• ThinkSystem RAID 940-16i 8GB Flash PCIe 12Gb Adapter
• ThinkSystem RAID 940-32i 8GB Flash PCIe 12Gb Adapter
• x16 PCIe 1610-8P adapter
Network OCP Ethernet adapter with 1G/10G base-T and 10G/25G/50G SPF+
Fans
• Eight (60 mm x 38 mm / 60 mm x 56 mm) internal single/dual rotor system fans (N+1
redundancy) :
– Slot 1, 3, 4, 6: single-fan single/dual-rotor module
– Slot 2, 5: dual-fan single/dual-rotor module
• Four fans for 4U PCIe riser cages (Two fans for each unit)
Chapter 1. Introduction 5
