Lenovo ThinkSystem SR860 V2 - Page 131

Three backplanes
Three AnyBay backplanes
8i + 16i RAID adapters
SAS/SATA cable routing PCIe cable routing
Length
To
NVMe
connector
Length
To
1
665 mm
C0 (8i)
1 0-1, 2-3 670 mm
PCIe 1 (on-board)
2
860 mm
C0 (16i)
2 4-5, 6-7 910 mm
PCIe 2 (on-board)
3
1000 mm
C1 (16i)
3 0-1, 2-3 530 mm
PCIe 3 (tray)
4 4-5, 6-7 670 mm
PCIe 6 (tray)
5 0-1, 2-3 1100 mm
C0, C1 (Slot 10)
6 4-5, 6-7 1100 mm
C0, C1 (Slot 12)
Chapter 3. Internal cable routing 123
