x16/x16
PCIe
FH
riser cage
See
this
section
to
locate
the
connectors
in
the
x16/x16
4U
PCIe riser
cage.
Figure 15.
x16/x16 PCIe
FH
Riser
Cage
Table
12.
Connectors on
x16/x16
PCIe
FH
Riser
Cage
1
Auxiliary power
connector
3
PCI Express
3.0
x16
(slot 2/10)
2
Auxiliary power
connector
4
PCI Express
3.0
x16
(slot 4/12)
36
ThinkSystem SR860
V2Setup Guide
