Lenze E82EV751K4C User Manual

Basic units in the power range 45 ... 55 kW
Thermally separated mounting (push-through technique)
5
Basic device installation
5.6
5.6.4
L
5.6-4
EDS82EV903-1.0-11/2002
5.6.4 Thermally separated mounting (push-through technique)
For mounting in push-through technique use the controller type E82 D V... . The
delivery package includes all parts and components required for mounting.
d2
d2
d2
d b
g
a1
a
d1
b1
h
h
c1
c2
c3
c4
e
e1
8200vec302
Fig. 5.6-4 Dimensions for thermally separated mounting 45 ... 55 kW
Dimensions [mm]
8200 vector a a1 b b1 c1 c2 c3 c4 d d1 d2 e e1 g h
E82DV453K4B
3
7
3
3
4
0
5
4
3
5
1
0
4
5
9
2
5
1
7
2
5
2
6
5
5
2
5
4
5
1
4
5
2
8
5
1
6
3
5
7
9
E82DV553K4B
373 340 543 510 45 92.5 172.5 265 525 45 145 285 163.5 7 9
Mounting cutout in the control cabinet
Dimensions [mm]
8200 vector a a1
E82DV453K4B
3
7
3
3
4
0
E82DV553K4B
373 340
