Parameter setting with the XT EMZ9371BC keypad
Changing and saving par ameters
9
Parameter setting
9.4
9.4.4
L
9.4-5
EDS82EV903-1.0-11/2002
9.4.4 Changing and saving parameters
)
))
) Note!
Your settings in the menus are always stored in the parameter set
1.
If you want to store settings in the parameter sets 2, 3 or 4, two
menus can be used:
l In menu 2 ”Code list” it is possible to access to all available
codes.
l In menu 7 ”Param managm” it is possible to copy parameter
set 1 into the oter parameter sets.
– Please note, that with copying the ”own basic setting”
will be overwritten by the settings of parameter set 1!
Step Keys Action
1. Select menu
zyZY
Select the desired menu with arrow keys
2. Change to the code level
Z
Display of first code in the menu
3. Select code or subcode
yz
Display of current parameter value
4. Change to parameter level
V
p
y
p
5. If SHPRG is displayed, inhibit controller
S
The drive is idling
6. Change parameters
A)
ZY
Move cursor under the digit to be changed
B)
yz
Change digit
)
Ty
Tz
Change digit quickly
7. Accept changed parameter
Display of SHPRG or SHPRG p
TV
Confirm change to accept parameter
Display ”OK”
Display p - The parameter was accepted immediately
8. If necessary, enable controller
U
The drive should be running again
9. Change to the code level
A)
V
Display of operation level
B)
V
Display of the code with changed parameters
10. Change further parameters Restart ”loop” at step 1. or step 3.
