Braking operation with external brake resistor
8200 vector 15 ... 90 kW
13
Braking operation
13.4
13.4.2
L
13.4-5
EDS82EV903-1.0-11/2002
Fuses and cable cross-sections (EMB9351-E and EMB9352-E)
Type DC fu se (F4, F5)
1)
Cable cross-section
T
y
p
e
VDE UL mm
2
AWG
EMB9351 -E
EMB9352 -E
50 A 40 A K5 j6 10
1)
Recommended for combinations in which more than two devices (controller or brake chopper/brake module) are
connected to +UG, –UG (connection in parallel of brake choppers/brake modules or DC-bus connection)
Obser ve the national and regional regulations!
Dimensions for standard mounting (scope of supply)
9350E001
Type Dimensions [mm] Weight [kg]
T
y
p
e
a b b1 c d e g k
W
e
i
g
h
t
[
k
g
]
EMB9351 -E 52 384 350 26 365 186 6.5 30 2.6
EMB9352 -E
5
2
3
8
4
3
5
0
2
6
3
6
5
1
8
6
6
.
5
3
0
2.2
