9.2 Important notes
The controller functions can be adapted to your application by setting
parameters. The parameters are set using a keypad or PC or via the parameter
channel of a bus system.
The function library describes in detail the functions and the functional block
diagram contains all the signals to be configured.
The function parameters are stored as numerical codes:
l Codes are marked in the text with a ”C” (e.g. C0002).
l The code table gives a quick overview over all codes. The codes are sorted
according to their numbers and can be used as reference.
(¶ 10.20-1)
For quick parameter setting two operating modules (keypad) are available in
different designs. Both serve simultaneously as status display, fault diagnostics
and parameter transfer to other controllers:
Keypad
E82ZBC
Keypad XT
EMZ9371BC
Canbeusedwith 8200 vector, 8200 mot e c,
starttec
8200 vector, 8200 mo t e c,
starttec, Drive PLC, 9300 vector,
9300 servo
Operator buttons 8 8
Text display yes yes
Plain text display no yes
Menu structure User menu, code list User-specific menus
Configurable menu (“user menu”) yes yes
Menu for quick commissioning (”Quickstart”) no yes
Predefined basic configurations no yes
Non- volatile memor y for parameter transfer yes yes
Password protection yes yes
Hand terminal yes yes
Inst allation into control cabinet yes no
Enclosure IP 55 IP 20
Detailed description ^ 9.3-1 ^ 9.4- 1
