Basic units in the power range 3 ... 11 kW
Wiring according to EMC (installation of a CE-typical drive system)
6
Basic unit wiring
6.5
6.5.1
L
6.5-2
EDS82EV903-1.0-11/2002
6.5.1 Wiring according to EMC (installation of a CE-typical drive system)
Drives comply with the EMC Directive if they are installed according to the
guidelines for CE-typical drive systems. The user is responsible for the
compliance of his application with the EC directives.
)
))
) Note!
l Control cables and mains cables must be separated from the
motor cable to avoid interferences.
l Control cable must always be shielded.
l We recommend to shield the supply cable for the PTC or
thermal contact and route it separately from the motor cable.
l If the cores for motor connection and PTC or thermal contact
are together in one cable with a common shield:
– In order to reduce interference injections on the PTC cable,
we recommend to install additionally the PTC module type
E82ZPEx.
l An optimum HF shield connection of the motor cable can be
reached by using the terminal
2 for motor PE and motor
shield.
