Lenze E82EV751K4C User Manual

Parameter setting with the XT EMZ9371BC keypad
Menu structure
9
Parameter setting
9.4
9.4.8
L
9.4-10
EDS82EV903-1.0-11/2002
Main menu DescriptionSubmenus
No.
Description
DisplayNo.Display
3 Remote para Remote parameter setting
Only active with function module system bus (CAN)
4 Quick start Quick commiss ioning of s tandard applications
4.1 Keypad quick Function check
Frequency setpoint via keypad (C0140)
4.2 V/f quick Linear V/f-characteristic control
Frequency setpoint selectable analogically via potentiometer,
fixed setpoints (JOG) selectable via terminal
4.3 VectorCtrl qu Vector control
Frequency setpoint selectable analogically via potentiometer,
fixed setpoints (JOG) selectable via terminal
5 Short setup Quick configuration of predefined applications
Obser ve the different key functions for the change from
submenu to configuration menu!
• Press TV until ”Loading...” is displayed:
– Change to configuration menu, Lenze settings are
loaded
– Required signals are linked automatically
– Complete the configuration subsequently
• Press Z :
– Change to configuration menu without linking signals
– You can edit existing configurations
Speed control in the operating mode ”U/f characteristic control”
5.1 Speed-Ctrl 0 Frequency setpoint analog via analog input 1 (AIN1)
Actual frequency digital via frequency input (DFIN)
5.1.1 Freq setpt Frequency setpoint configuration
5.1.2 Actual value Actual frequenc y configuration
5.1.3 PCTRL setup Process controller configuration
5.1.4 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.1.5 Motor param Motor current control, motor monitoring configuration
5.2 Speed-Ctrl 1 Frequency setpoint via paramete r channel (C0046)
Actual frequency digital via frequency input (DFIN)
5.2.1 Freq setpt Frequency setpoint configuration
5.2.2 Actual value Actual frequenc y configuration
5.2.3 PCTRL setup Process controller configuration
5.2.4 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.2.5 Motor param Motor current control, motor monitoring configuration
5.3 Speed-Ctrl 3 Frequency setpoint via AIF process data channel (AIF-IN.W1)
Actual frequency digital via frequency input (DFIN)
5.3.1 Freq setpt Frequency setpoint configuration
5.3.2 Actual value Actual frequenc y configuration
5.3.3 PCTRL setup Process controller configuration
5.3.4 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.3.5 Motor param Motor current control, motor monitoring configuration
5.4 Speed-Ctrl 5 Operation with function module system bus (CAN) on FIF
Frequency setpoint via process data channel (CAN-IN1.W2)
Actual frequency via process data channel (CAN-IN1.W3)
5.4.1 CAN managem Set up system bus (CAN) communication
5.4.2 Freq setpt Frequency setpoint configuration
5.4.3 Actual value Actual frequenc y configuration
5.4.4 PCTRL setup Process controller configuration
5.4.5 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.4.6 Motor param Motor current control, motor monitoring configuration
