Configuration of analog and digital setpoints and actual values
Setpoints via keypad
10
Function library
10.8
10.8.6
L
10.8-15
EDS82EV903-1.0-11/2002
10.8.6 Setpoints via keypad
The setpoint can be selected via the keypad.
The keypad setpoint is added to the main setpoint.
)
))
) Note!
l Setpoints selected by means of the keypad are stored when
the controller is disconnected from the mains or operation is
interrupted.
l The drive can start again after controller enable!
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0044* Setpoint 2
(NSET1-N2)
-650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
• Selectio n, if C0412/2 = FIXED-FREE (not
assigned)
• Displa y if C0412/2 is linked with a signal
source
^ 10.8-15
C0046* Setpoint 1
(NSET1-N1)
-650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
• Selectio n, if C0412/1 = FIXED-FREE (not
assigned)
• Displa y if C0412/1 is linked with a signal
source
^ 10.8-15
C0140* Additive frequency
setpoint
(NSET1-NADD)
0.00 -650.00 {0.02 Hz} 650.00 • Selection via function j of the
keypad or the parameter channel
• Is added to main setpoint
• Value is stored when switching the
mains or removing the keypad
^ 10.8-15
With keypad E82ZBC
The setpoint can be easily set via the function j:
1. Select with w or x to activate the function j .
2. Set the setpoint using y or z
– If the controller is enabled, the changed setpoint has a direct effect on the
drive.
– The setpoint is saved when the controller is inhibited. After the controller
has been enabled, the drive accelerates or decelerates to the setpoint set
last.
)
))
) Note!
j writes the setpoint under C0140. The setpoint can also be
selected directly under C0140.
Description
Setpoint selection with keypad
E82ZBC
