Configuration of analog and digital setpoints and actual values
Setpoints via fixed setpoints (JOG)
10
Function library
10.8
10.8.5
L
10.8-14
EDS82EV903-1.0-11/2002
Operation without application I/O
l The signal NSET1-JOG1/3 must be combined with a digital input signal
under C0410/1.
l The signal NSET1-JOG2/3 must be combined with a digital input signal
under C0410/2.
Active setpoint Level at
NSET1-JOG1/3 NSET1-JOG2/3
other setpoint source LOW LOW
JOG 1 HIGH LOW
JOG 2 LOW HIGH
JOG 3 HIGH HIGH
)
))
) Note!
In addition to the free configuration under C0410 you can also use
the fixed assignment under C0007 to combine the function with
digital inputs.
Operation with application I/O
l The signal NSET1-JOG1/3/5 must be combined with a digital input signal
under C0410/1.
l The signal NSET1-JOG2/3/6/7 must be combined with a digital input signal
under C0410/2.
l The signal NSET1-JOG4/5/6/7 must be combined with a digital input signal
under C0410/33.
Active setpoint Level at
NSET1-JOG1/3/5/7 NSET1 -JOG2/3/6/7 NSET1-JOG4/5/6/7
other setpoint source LOW LOW LOW
JOG 1 HIGH LOW LOW
JOG 2 LOW HIGH LOW
JOG 3 HIGH HIGH LOW
JOG 4 LOW LOW HIGH
JOG 5 HIGH LOW HIGH
JOG 6 LOW HIGH HIGH
JOG 7 HIGH HIGH HIGH
l The maximum output frequency (C0011) also limits the fixed setpoints
(JOG).
l The minimum output frequency (C0010) does not limit the fixed setpoints
(JOG).
l Fixed setpoints (JOG) have priority over the analog setpoint 1 (NSET1-N1)
and over the analog setpoint 2 (NSET1-N2).
l The additional setpoint (PCTRL1-NADD) is added to the fixed setpoints.
The display of the parameter can be related to a process variable. (
^ 10.16-1)
Activation
Influence on other setpoints
Tip
