Braking operation with external brake resistor
Wiring of brake resistor
13
Braking operation
13.4
13.4.5
L
13.4-10
EDS82EV903-1.0-11/2002
13.4.5 Wiring of brake resistor
l Brake resistors can become very hot. Therefore brake resistors must be
mounted in a way that the high temperatures do not damage anything.
l In order to prevent the brake resistors from being damaged due to
overload,
– Provide a safety switch-off of the brake resistor!
– Use temperature contacts of the brake resistor (T1/T2) as control
contacts to disconnect the controller from the mains!
)
))
) Note!
Shielding of cables are only required to comply with the existing
standards (e.g. VDE 0160, EN 50178).
