Configuration of analog and digital setpoints and actual values
Setpoint changeover (hand/remote changeover)
10
Function library
10.8
10.8.8
L
10.8-18
EDS82EV903-1.0-11/2002
l
Invert X3/E6 with C0411 = 32.
l Assign X3/E6 to the subcode C0410/17 with C0410/17 = 6.
l The setpoint can be selected under C0044 using the keypad or PC.
l If C0411 = 0 is set, the remote operation is active again.
l JOG frequency are not effected by a manual/remote changeover.
l Function j of the keypad E82ZBC simultaneously acts on NSET1-N1 and
NSET-N2.
– Use C0046 (NSET1-N1) and C0044 (NSET1-N2) for separated setpoint
selection.
)
))
) Note!
The keypad key s is not active in manual operation!
Example
Influence on other setpoints
