Parameter setting with the XT EMZ9371BC keypad
Menu structure
9
Parameter setting
9.4
9.4.8
L
9.4-11
EDS82EV903-1.0-11/2002
Main menu DescriptionSubmenus
No.
Description
DisplayNo.Display
5.5 Speed-Ctrl 7 Operation with fieldbus function module on FIF (DRIVECOM
control)
Frequency setpoint via process data channel
Actual frequency via process data channel
5.5.1 FIF managem Set up fieldbus communication
5.5.2 Freq setpt Frequency setpoint configuration
5.5.3 Actual value Actual frequenc y configuration
5.5.4 PCTRL setup Process controller configuration
5.5.5 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.5.6 Motor param Motor current control, motor monitoring configuration
Speed control in the operating mode ”U/f characteristic control”
5.6 OpenLoopV/f 0 Frequency setpoint analog via analog input 1 (AIN1)
5.6.1 Freq setpt Frequency setpoint configuration
5.6.2 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.6.3 Motor param Motor current control, motor monitoring configuration
5.7 OpenLoopV/f 1 Frequency setpoint via parameter channel (C0046)
5.7.1 Freq setpt Frequency setpoint configuration
5.7.2 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.7.3 Motor param Motor current control, motor monitoring configuration
5.8 OpenLoopV/f 3 Frequency setpoint via AIF process data channel (AIF-IN.W1)
5.8.1 Freq setpt Frequency setpoint configuration
5.8.2 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.8.3 Motor param Motor current control, motor monitoring configuration
5.9 OpenLoopV/f 5 Operation with function module system bus (CAN) on FIF
Frequency setpoint via process data channel (CAN-IN1.W2)
5.9.1 CAN managem Set up system bus (CAN) communication
5.9.2 Freq setpt Frequency setpoint configuration
5.9.3 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.9.4 Motor param Motor current control, motor monitoring configuration
5.10 OpenLoopV/f 7 Operation with fieldbus function module on FIF (DRIVECOM
control)
Frequency setpoint via process data channel
5.10.1 FIF managem Set up fieldbus communication
5.10.2 Freq setpt Frequency setpoint configuration
5.10.3 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.10.4 Motor param Motor current control, motor monitoring configuration
Speed control in the operating mode ”Vector control”
5.11 Vector-Ctrl 0 Frequency setpoint analog via analog input 1 (AIN1)
5.11.1 Freq setpt Frequency setpoint configuration
5.11.2 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.11.3 Motor param Motor current control, motor monitoring configuration
5.11.4 Motor ident Motor parameter identification
5.12 Vector-Ctrl 1 Frequency setpoint via parameter channel (C0046)
5.12.1 Freq setpt Frequency setpoint configuration
5.12.2 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.12.3 Motor param Motor current control, motor monitoring configuration
5.12.4 Motor ident Motor parameter identification
