Parameter setting with the XT EMZ9371BC keypad
Menu structure
9
Parameter setting
9.4
9.4.8
L
9.4-12
EDS82EV903-1.0-11/2002
Main menu DescriptionSubmenus
No.
Description
DisplayNo.Display
5.13 Vector-Ctrl 3 Frequency setpoint via AIF process data channel (AIF-IN.W1)
5.13.1 Freq setpt Frequency setpoint configuration
5.13.2 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.13.3 Motor param Motor current control, motor monitoring configuration
5.13.4 Motor ident Motor parameter identification
5.14 Vector-Ctrl 5 Operation with function module system bus (CAN) on FIF
Frequency setpoint via process data channel (CAN-IN1.W2)
5.14.1 CAN managem Set up system bus (CAN) communication
5.14.2 Freq setpt Frequency setpoint configuration
5.14.3 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.14.4 Motor param Motor current control, motor monitoring configuration
5.14.5 Motor ident Motor parameter identification
5.15 Vector-Ctrl 7 Operation with fieldbus function module on FIF (DRIVECOM
control)
Frequency setpoint via process data channel
5.15.1 FIF managem Set up fieldbus communication
5.15.2 Freq setpt Frequency setpoint configuration
5.15.3 f limit/ramp Output frequency, acceleration time, deceleration time
configuration
5.15.4 Motor param Motor current control, motor monitoring configuration
5.15.5 Motor ident Motor parameter identification
Sensorless torque control with speed limitation
5.16 Torque-Ctrl 0 Torque setpoint analog via analog input 1 (AIN1)
Speed limitation via maximum fre quency C0011
5.16.1 Torque setpt Torque setpoint configuration
5.16.2 f limit Speed limitation configuration
5.16.3 Motor param Motor current control, motor monitoring configuration
5.16.4 Motor ident Motor parameter identification
5.17 Torque-Ctrl 1 Torque setpoint analog via parameter channel (C0047)
Speed limitation via maximum fre quency C0011
5.17.1 Torque setpt Torque setpoint configuration
5.17.2 f limit Speed limitation configuration
5.17.3 Motor param Motor current control, motor monitoring configuration
5.17.4 Motor ident Motor parameter identification
5.18 Torque-Ctrl 2 Analog torque setpoint via analog input 1 (AIN1)
Analog speed limitation via analog input 2 (AIN2)
5.18.1 Torque setpt Torque setpoint configuration
5.18.2 f limit Speed limitation configuration
5.18.3 Motor param Motor current control, motor monitoring configuration
5.18.4 Motor ident Motor parameter identification
5.19 Torque-Ctrl 3 Torque setpoint via AIF process data channel (AIF-IN.W1)
Speed limitation via maximum fre quency C0011
5.19.1 Torque setpt Torque setpoint configuration
5.19.2 f limit Speed limitation configuration
5.19.3 Motor param Motor current control, motor monitoring configuration
5.19.4 Motor ident Motor parameter identification
5.20 Torque-Ctrl 5 Operation with function module system bus (CAN) on FIF
Torque setpoint via process data channel (CAN-IN1.W2)
Speed limitation via process data channel (CAN-IN1.W3)
5.20.1 CAN managem Set up system bus (CAN) communication
5.20.2 Torque setpt Torque setpoint configuration
5.20.3 f limit Speed limitation configuration
5.20.4 Motor param Motor current control, motor monitoring configuration
5.20.5 Motor ident Motor parameter identification
