Basic units in the power range 45 ... 55 kW
6
Basic unit wiring
6.7
L
6.7-1
EDS82EV903-1.0-11/2002
6.7 Basic units in the power range 45 ... 55 kW
Drives comply with the EMC Directive if they are installed according to the
guidelines for CE-typical drive systems. The user is responsible for the
compliance of his application with the EC directives.
)
))
) Note!
l Control cables and mains cables must be separated from the
motor cable to avoid interferences.
l Control cable must always be shielded.
l We recommend to shield the supply cable for the PTC or
thermal contact and route it separately from the motor cable.
