Lenze E82EV751K4C User Manual

Free connection of analog signals
Free configuration of analog outputs
10
Function library
10.12
10.12.2
L
10.12-5
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0419 Possible analog signals for C0419 ^
v
(
t
)
0 Output frequency (MCTRL1-NOUT+SLIP) 6V/12mA/5.85kHz ≡C0011
10.12-4
(cont.)
1
Device utilisation (MCTRL1-MOUT) at V/f
characteristic control (C0014 = 2 or 3)
3 V/6 mA/2.925 kHz ≡ Rated active
inverter current (active current/C0091)
Actual motor torque (MCTRL1-MACT) at vector
control (C0014 = 4) or sensorless torque control
(C0014 = 5)
3 V/6 mA/2.925 kHz ≡ Rated motor torque
2 Apparent motor current (MCTRL1-IMOT) 3 V/6 mA/2.925 kHz ≡ Rated inverter
current
3 DC-bus voltage (MCTRL1-DCVOLT) 6V/12mA/5.85kHz ≡ DC 1000 V (400 V-
mains
6V/12mA/5.85kHz
≡ DC 380 V (230 V
mains)
4 Motor power 3 V/6 mA/2.925 kHz ≡ Rated motor power
5 Motor voltage (MCTRL1-VOLT) 4.8 V/9.6 mA/4.68 kHz ≡ Rated motor
voltage
6 1/output frequency (1/C0050) (MCTRL1-1/NOUT) 2 V/4 mA/1.95 kHz ≡ 0.5 × C0011
7 Output frequenc y with limits
(DCTRL1-C0010...C0011)
0 V/0 mA/4 mA/0 kHz ≡ f=f
min
(C0010)
6V/12mA/5.85kHz
≡ f=f
max
(C0011)
8
Operation with process controller (C0238 = 0.1):
Act. process controller value (PCTRL1-ACT)
6V/12mA/5.85kHz ≡ C0011
Operation without process controller (C0238 = 2):
Output frequency without slip (MCTRL1-NOUT)
