Braking operation with external brake resistor
8200 vector 15 ... 90 kW
13
Braking operation
13.4
13.4.2
L
13.4-7
EDS82EV903-1.0-11/2002
Mounting/dimensions for “cold plate” technique
Variant V003 is required for mounting the brake chopper or brake module “cold
plate” technology.
9350E003
Dimensions [mm]
Type a b b1 c d e g Weight [kg]
EMB9351 -C-V003 52 381 350 34 367 104 6.5 2.6
EMB9352 -C-V003
5
2
3
8
1
3
5
0
3
4
3
6
7
1
0
4
6
.
5
2.2
Thermal resistance R
th
(transition cooler / cooling medium)
Type Power to be dissipated P
V
[W] CoolingpathR
th
[°C/W]
EMB9351 -C-V003 100 ≤ 0.3
EMB9352 -C-V003 63
≤
0
.
3
