5 Commissioning
General parameter setup (Favorites)
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 31
Tuning parameters
For most applications the
default tuning parameters
can be used:
P no.
Type
Name
Default setting
Unit
P305:0
Motor control
Switching frequency
21: 8kHz var/opt/4kHz
min.
kHz
P308:1
Motor control
Load at 60 sec
150
%
P316:1
Motor control
V/f boost: static
0.4%...2.5%
Typecode dependent
%
P324:0
Motor control
Max current
200.0
%

If the performance is insufficient during operation, see chapter “Motor Control setup” for tuning the pa-
rameters above.
Control selection
The i500 can be controlled
from various locations and
in different ways.
P no.
Type
Name
Default setting
Unit
P200:0
Basic Setup
Control source
0: Flexible
–
Basic functionalities:
 Inverter enable
Enables the inverter. Signal must have the state TRUE (by Input or setting) to be able to start the motor.
 Run/Stop
Enables the running of the motor. Can be used as single signal or in combination with the signals Start For-
ward / Start Reverse. Signal must have the state TRUE (by Input or setting) to be able to start the motor.
 Start Forward / Start Reverse
Used to start the motor (Positive edge triggered). Stop is down with the Run/Stop signal.
 Run Forward / Run Reverse
Used to run and stop the motor (Maintained signals)
 Rotation invertion
Inverts the speed setpoint
 Fault Reset
For a successful reset of a fault it is necessary to correct the condition that caused the fault first. Afterwards
there are different possibilities to reset the fault:
 Quick Stop (QSP) works as “pause” / “zero-speed” function. (The QSP ramp time can be set in P225:0)
i
In Flexible Control mode (P200:0) either Inverter enable (P400:1) or Run/Stop (P400:2) must be assigned
to I/O to ensure that the drive can always be stopped!
(Exception: Inverter is controlled from network, Network enable (P400:37) is HIGH)

See chapter “6.2.3 Control examples” on page 39 for control application examples.
See chapter “6.6.1 Function list (Run/Stop/Start/Jog/Reverse)” on page 69 for detailed information
P no.
Type
Name
Default setting
Unit
P400:1
I/O Setup
Inverter enable
1: TRUE
–
P400:2
I/O Setup
Run/Stop
11: Digital input 1
–
P400:3
I/O Setup
Quick Stop [QSP]
0: Not connected
–
