Lenze i510 - Page 33

5 Commissioning
General parameter setup (Favorites)
Lenze · Inverter i510 / i550 - Cabinet · Operation Manual · 0.4 EN · 02/2016 33
Analog output 1
Analog output can be used
as a feedback for your con-
trol system. Select the cor-
rect scaling and range (See
Fig. 14 for Scaling):
P no.
Type
Name
Default setting
Unit
P440:1
I/O Setup
AO1 configuration
1: 0...10VDC
–
P440:2
I/O Setup
AO1 function
1: Output freq.
–
P440:3
I/O Setup
AO1 function @ min
0
–
P440:4
I/O Setup
AO1 function @ max
1000
–
Preset frequency
Define your basic preset
frequency if required:
P no.
Type
Name
Default setting
Unit
P450:1
I/O Setup
Preset 01
20.0
Hz
P450:2
I/O Setup
Preset 02
40.0
Hz
P450:3
I/O Setup
Preset 03
50.0/60.0 *Typecode
dependent
Hz
P450:4
I/O Setup
Preset 04
0.0
Hz
