Open and close screw connecon of the cover
For wiring purposes, loosen the 4 screws in the cover using a Phillips head screwdriver. Aer
compleng the wiring, close the cover again using the 4 screws to ensure that the degree of
protecon is maintained.
PH2
1.2 Nm
(10.6 lb-in)
4x
Cable glands
Always use cable glands with long thread.
