Lenze i550 Mounting And Switch-On Instructions

1-phase mains connecon 120 V
Rated data
The output currents apply to these operang condions:
•
At switching frequency 2 kHz or 4 kHz: Ambient temperature max. 45 °C (113 °F).
•
At switching frequency 8 kHz, 12 kHz or 16 kHz: Ambient temperature max. 40 °C (104 °F).
Inverter I55AP
137A 175A 211A
Rated power P
rated
kW 0.37 0.75 1.1
Rated power P
rated
HP 0.5 1 1.5
Mains voltage range 1/PE AC 90 V ... 132 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 - 230/240 V
Rated mains current
without mains choke A 9.6 16.8 22.9
with mains choke A -
Apparent output power kVA 0.9 1.6 2.3
Rated output current
2 kHz A 2.4 4.2 6
4 kHz A 2.4 4.2 6
8 kHz A 2.4 4.2 6
12 kHz A 2.2 3.8 5.4
16 kHz A 1.6 2.8 4
Power loss
2 kHz W 19 30 38
4 kHz W 20 32 40
8 kHz W 24 40 51
12 kHz W 23 38 54
16 kHz W 22 35 49
Cyclic mains switching 3 mes per minute
Max. motor cable length
shielded
without EMC category m 50
Category C1 (2 kHz, 4 kHz,
8kHz)
m -
Category C2 (2 kHz, 4 kHz, 8
kHz)
m -
Category C3 (2 kHz, 4 kHz, 8
kHz)
m -
Max. motor cable length
unshielded
without EMC category m 60 80
Degree of protecon
EN IP31 IP66 IP31 IP66 IP31 IP66
NEMA Type 1 Type 4X Type 1 Type 4X Type 1 Type 4X
Weight m kg 1.7 1.8 2.6 2.7 2.6 2.7
Weight m lb 3.7 4 5.7 6 5.7 6
Technical data
1-phase mains connecon 120 V
Rated data
178

Lenze i550 Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Safety	STO (Safe Torque Off)
Voltage Range	380 V to 480 V
Control Type	Vector control, V/f control
Communication Interfaces	CANopen, EtherCAT, PROFINET, Ethernet/IP
Mains Voltage	3-phase 380 V to 480 V
Input Voltage	3-phase 380 V to 480 V
Output Voltage	0 to Mains Voltage
Frequency Range	0 Hz to 300 Hz
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Ambient Temperature	-10°C to 50°C
