Lenze i550 - Terminal Data; Fusing Data

Terminal data
Rated power P
rated
kW 0.37 ... 0.37 0.75 ... 1.1
Connecon descripon Mains connecon
Connecon X100
Connecon type Non-pluggable
Max. cable cross-secon mm² 4 4
Max. cable cross-secon AWG 10 10
Stripping length mm 10 10
Stripping length in 0.4 0.4
Tightening torque Nm 0.5 0.5
Tightening torque lb-in 4.4 4.4
Required tool 1.2 x 8.0 0.6 x 3.5
Rated power P
rated
kW 0.37 ... 1.1
Connecon descripon PE connecon
Connecon PE
Max. cable cross-secon mm² 6
Max. cable cross-secon AWG 10
Stripping length mm 10
Stripping length in 0.4
Tightening torque Nm 2
Tightening torque lb-in 18
Required tool T20
Rated power P
rated
kW 0.37 ... 0.37 0.75 ... 1.1
Connecon descripon Motor connecon
Connecon X105
Connecon type Non-pluggable
Max. cable cross-secon mm² 4 4
Max. cable cross-secon AWG 10 10
Stripping length mm 10 10
Stripping length in 0.4 0.4
Tightening torque Nm 0.5 0.5
Tightening torque lb-in 4.4 4.4
Required tool 1.2 x 8.0 0.6 x 3.5
Fusing data
A residual current device (RCD) is oponal.
Fusing data for UL/NEC compliant installaons: 4Fusing data ^ 135
Inverter Fuse Circuit breaker RCD
Characterisc
Max. rated
current
Characterisc
Max. rated
current
Type
A A mA
I55AP137A..3 gG/gL, gRL 32 B 32 ≥30 Typ B
I55AP137A..7 gG/gL, gRL 32 B 32 ≥30 Typ B
I55AP175A..3 gG/gL, gRL 32 B 32 ≥30 Typ B
I55AP175A..7 gG/gL, gRL 32 B 32 ≥30 Typ B
I55AP211A..3 gG/gL, gRL 32 B 32 ≥30 Typ B
I55AP211A..7 gG/gL, gRL 32 B 32 ≥30 Typ B
Electrical installaon
Mains connecon
1-phase mains connecon 120 V
138
