Lenze i550 Mounting And Switch-On Instructions

Mains connecon
The connecon diagram is considered exemplary for all voltage and power classes. Deviang mains
connecon diagrams can be found in the corresponding chapters.
X277 X276
Modbus TCP
X267
X266
EtherNet/IP
X257 X256
PROFINET
OUT
X247
IN
X246
EtherCAT
CL TA/
COM/CG
H TB/C
X216
Modbus RTU
TA/CL
COM/CG
TB/CH
X216
CANopen
C/Q
L-
L+
X316
IO-Link
Safety STO
X1
SIA
GS
SIB
DC SELV PELV 24 V /
(+19.2 … +28.8 V)
"
1k ... 10k
0 ... 10 V
S1
DI3 DI4
100 mA
4.4k
+24 V +10 V
4.4k 4.4k 4.4k
4.4k
10 mA
Standard I/O
GND
1 DO
1 DI 2 DI 3 DI 4 DI 5 DI
24E
GND
1 AI 2 AI
10V
GND
1 AO
24V
24E
X3
+
X109
T1 T2
""
M
3~
+
J
J
X105
W
-UG
Rb2/+UG
V
U
Rb1
X9
NC
NO
COM
AC 240 V
3 A
X100
L1
L2/N
L3
F1
…
F3
Q1
3/N/ 400 VPE AC
3/ PE
340 V ... 528 VAC
45 Hz ... 65 Hz
PE
N
L3
L2
L1
+
S1 Start/Stop
Fx Fuses
Q1 Mains contactor
--- Dashed line = opons
Electrical installaon
Mains connecon
136

Lenze i550 Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Safety	STO (Safe Torque Off)
Voltage Range	380 V to 480 V
Control Type	Vector control, V/f control
Communication Interfaces	CANopen, EtherCAT, PROFINET, Ethernet/IP
Mains Voltage	3-phase 380 V to 480 V
Input Voltage	3-phase 380 V to 480 V
Output Voltage	0 to Mains Voltage
Frequency Range	0 Hz to 300 Hz
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Ambient Temperature	-10°C to 50°C
