HINWEIS
▶
UL marking
▶
Internal overload protecon rated for 125 % of the rated FLA.
▶
Marquage UL
▶
Protecon contre les surcharges conçue pour se déclencher à 125 % de l'intensité assignée à pleine
charge.
Absicherungsdaten
Branch Circuit Protecon (BCP)
Short Circuit Current Rangs (SCCR) with Standard Fuses and Circuit Breaker
(Tested per UL61800-5-1, reference UL le E132659)
These devices are suitable for motor group installaon when used with Standard Fuses and Circuit Breaker.
For single motor installaon, if the fuse value indicated is higher than 400 % of the motor current (FLA), the
fuse value has to be calculated. If the value of the fuse is below two standard rangs, the nearest standard
rangs less than the calculated value shall apply.
Inverter Standard Fuses (UL248) Circuit Breaker (UL489)
Mains Rated power SCCR Max. rated current Class SCCR Max. rated current
kW HP kA A kA A
120 V, 1-ph 0.37 0.5 5 30 CC, CF, J, T 5 30
120 V, 1-ph 0.75 1 5 30 CC, CF, J, T 5 30
120 V, 1-ph 1.1 1.5 5 30 CC, CF, J, T 5 30
230 V, 1-ph 0.37 0.5 5 40 CF, J, T 5 30
230 V, 1/3-ph 0.37 0.5 5 40 CF, J, T 5 30
230 V, 1-ph 0.55 0.75 5 40 CF, J, T 5 30
230 V, 1/3-ph 0.55 0.75 5 40 CF, J, T 5 30
230 V, 1-ph 0.75 1 5 40 CF, J, T 5 30
230 V, 1/3-ph 0.75 1 5 40 CF, J, T 5 30
230 V, 1-ph 1.1 1.5 5 40 CF, J, T 5 30
230 V, 1/3-ph 1.1 1.5 5 40 CF, J, T 5 30
230 V, 1-ph 1.5 2 5 40 CF, J, T 5 30
230 V, 1/3-ph 1.5 2 5 40 CF, J, T 5 30
230 V, 1-ph 2.2 3 5 40 CF, J, T 5 30
230 V, 1/3-ph 2.2 3 5 40 CF, J, T 5 30
230 V, 3-ph 3 4 5 80 CF, J, T - -
230 V, 3-ph 4 5 5 80 CF, J, T - -
230 V, 3-ph 5.5 7.5 5 80 CF, J, T - -
230 V, 3-ph 7.5 10 5 80 CF, J, T - -
230 V, 3-ph 11 15 5 80 CF, J, T - -
480 V, 3-ph 0.37 0.5 5 30 CC, CF, J, T 5 30
480 V, 3-ph 0.55 0.75 5 30 CC, CF, J, T 5 30
480 V, 3-ph 0.75 1 5 30 CC, CF, J, T 5 30
480 V, 3-ph 1.1 1.5 5 30 CC, CF, J, T 5 30
480 V, 3-ph 1.5 2 5 30 CC, CF, J, T 5 30
480 V, 3-ph 2.2 3 5 30 CC, CF, J, T 5 30
480 V, 3-ph 3 4 5 50 CF, J, T - -
480 V, 3-ph 4 5 5 50 CF, J, T - -
480 V, 3-ph 5.5 7.5 5 50 CF, J, T - -
480 V, 3-ph 7.5 10 5 50 CF, J, T - -
480 V, 3-ph 11 15 5 50 CF, J, T - -
600 V, 3-ph 0.75 1 5 20 CC, CF, J, T - -
600 V, 3-ph 1.5 2 5 20 CC, CF, J, T - -
600 V, 3-ph 2.2 3 5 20 CC, CF, J, T - -
Elektrische Installaon
Anschluss nach UL
Absicherungsdaten
39

Lenze i550 Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Safety	STO (Safe Torque Off)
Voltage Range	380 V to 480 V
Control Type	Vector control, V/f control
Communication Interfaces	CANopen, EtherCAT, PROFINET, Ethernet/IP
Mains Voltage	3-phase 380 V to 480 V
Input Voltage	3-phase 380 V to 480 V
Output Voltage	0 to Mains Voltage
Frequency Range	0 Hz to 300 Hz
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Ambient Temperature	-10°C to 50°C
