Lenze i550 Mounting And Switch-On Instructions

Modbus TCP
Typical topologies
Line Tree
M
R
Sn
S2S1
M
SWn
SW2
SW1
M Master SW Switch
S Slave
Bus-related informaon
Name Modbus TCP
Communicaon medium Ethernet 10 Mbps, 100 Mbps, half
duplex, full duplex
Use Connecon as Modbus TCP slave
Connecon system RJ45
Status display 2 LEDs
Connecon designaon Port 1: X276
Port 2: X277
Connecon descripon Modbus TCP
Connecon X276 X277
Connecon type RJ45
Basic network sengs
The rotary encoder switch allows you to set the last byte of the IP address.
x16 x1
Seng Value of last byte Resulng IP address
0x00 Value from parameter Value from parameter
0x01 ... 0xFE Switch posion 192.168.124.<switch posion>
0xFF Default seng 192.168.124.16
Electrical installaon
Networks
Modbus TCP
165

Lenze i550 Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Safety	STO (Safe Torque Off)
Voltage Range	380 V to 480 V
Control Type	Vector control, V/f control
Communication Interfaces	CANopen, EtherCAT, PROFINET, Ethernet/IP
Mains Voltage	3-phase 380 V to 480 V
Input Voltage	3-phase 380 V to 480 V
Output Voltage	0 to Mains Voltage
Frequency Range	0 Hz to 300 Hz
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Ambient Temperature	-10°C to 50°C
