Using accessories
Keypad
Keypad operang mode
Funcon of keypad keys in operang mode
In the operang mode, the keypad can be used for local control and for manual setpoint selecon.
Funcon of keypad keys in operang mode
Key Actuaon Condion Acon
Shortly Local keypad control acve.
Display "LOC"
Run motor.
Remote control acve
Display "REM"
Display "KSTOP"
Deacvate keypad triggered stop.
The motor remains at standsll.
Display changes from "KSTOP" to "STOP".
Shortly No Jog operaon Stop motor.
Display "KSTOP"
Shortly Operang mode Change to parameterisaon mode.
More than 3 s None (anyme possible) Save parameter sengs in the user memory of the
memory module.
Shortly During operaon Scroll through informaon in the above status line.
Shortly Manual setpoint selecon via keypad
acve.
Display "MAN"
Change frequency setpoint.
CTRL
Shortly Operang mode Acvate full keypad control
Display "ON?" à Conrm with
Control and setpoint selecon can now only be carried
out via keypad.
Renewed clicking: Exit full keypad control.
Display "OFF?" à Conrm with
R
F
Shortly Local keypad control acve.
Display "LOC"
Reversal of rotaon direcon.
Display "REV?" à Conrm with
