Lenze i550 - Page 180

Inverter I55AP
215B 215D 222B 222D
Rated power P
rated
kW 1.5 2.2
Rated power P
rated
HP 2 3
Mains voltage range 1/PE AC 170 V ... 264 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 - 230/240 V
Rated mains current
without mains choke A 16.7 22.5
with mains choke A -
Apparent output power kVA 2.6 3.6
Rated output current
2 kHz A 7 9.6
4 kHz A 7 9.6
8 kHz A 7 9.6
12 kHz A 6.3 8.6
16 kHz A 4.7 6.4
Power loss
2 kHz W 45 62
4 kHz W 48 66
8 kHz W 61 85
12 kHz W 65 91
16 kHz W 58 81
Cyclic mains switching 3 mes per minute
Max. motor cable length
shielded
without EMC category m 50
Category C1 (2 kHz, 4 kHz,
8kHz)
m -
Category C2 (2 kHz, 4 kHz, 8
kHz)
m 10 - 10 -
Category C3 (2 kHz, 4 kHz, 8
kHz)
m 35 - 35 -
Max. motor cable length
unshielded
without EMC category m 80
Degree of protecon
EN IP66 IP31 IP66 IP31 IP66
NEMA Type 4X Type 1 Type 4X Type 1 Type 4X
Weight m kg 2.7 2.5 2.6 2.7 2.5 2.6
Weight m lb 6 5.5 5.7 6 5.5 5.7
Technical data
1-phase mains connecon 230/240 V
Rated data
180
