7.3.2 Reading out logbook entries
With an online connection, the existing logbook entries can simply be displayed in the
»Engineer«. Alternatively, the logbook entries can also be read via the corresponding
parameters (e.g. using the internal keypad).
 How to display logbook entries in the »Engineer«:
1. Go to the Project view and select the 8400 BaseLine controller whose logbook
entries are to be read.
2. Click the icon or select the command OnlineGo online to build up an online
connection with the controller.
3. Select the Diagnostics tab from the Workspace.
4. Click Logbook.
•The Logbook dialog box appears
•Click Delete to delete an entry from the logbook.
•Click Export to export the entries from the logbook into a *.log file.
5. Click Previous to close the Logbook dialog box.
[7-5] Dialog area of the logbook
