Firmware 03.00 - DMS EN 5.0 - 07/2009 L 101
8400 BaseLine D | Software Manual
Motor control (MCTRL)
DC-injection braking
5.6.1 Manual DC-injection braking (DCB)
The DC-injection braking can be activated manually by assigning a digital input (E1 ... E4)
to the DCB function.
For HIGH-active inputs, DC-injection braking is active as long as the signal is at HIGH level.
When the hold time C107
(999.0 s = hold time has no time limit) has expired, the controller
sets the pulse inhibit (CINH).
