8400 BaseLine D | Software Manual
I/O terminals
Analog input
114 L Firmware 03.00 - DMS EN 5.0 - 07/2009
6.1.2 Parameter setting
Short overview of the parameters for the analog input:
6.1.3 Using the analog input as current input
The current source must be connected to the X4/GND and X4/A1U plug connector.
Code C034
, selection "1" and "2", serves to reconfigure the analog input 1 to a current
input if a load resistor of 250 Ω is connected externally in parallel.
Tip!
The selection "2" serves to implement a 4 ...20 mA current loop, e.g. for fault-
resistant speed setpoint selection.
Open-circuit monitoring
Use C598/1
to set an open circuit error response for the 4 ...20 mA current loop. This error
response is already activated in the Lenze setting!
Minimum and maximum output speed
The speed range required for the application is set via the selection of the output speeds:
The maximum output speed which can be parameterised in code C011
is reached with
a speed setpoint selection of 100 %.
This value depends on the setpoint source and is considered as the reference speed for
all other settings.
The value which can be parameterised in code C010
corresponds to the minimum
speed if
– the input of the LS_AnalogInput block is connected to the X4/A1U input terminal
(Lenze setting)
and
– a voltage of 0 V applies to the X4/A1U input terminal.
Parameter INFO
C010/1
Minimum analog setpoint
Minimum and maximum output speed
( 114)
C011
Maximum output speed (reference speed)
Minimum and maximum output speed
( 114)
C034
Configuration of analog input 1, evaluation of current (with external load resistor) or
voltage
C598/1
Resp. to open circuit AIN1
C026/1
Analog input 1: Offset
C027/1
Analog input 1: Gain
C028/1 Analog input 1: Voltage input signal
C029/1 Analog input 1: Current input signal
C033/1 Analog input 1: AIN1_nIn_a
Highlighted in grey = display parameter
