8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00011
178 L Firmware 03.00 - DMS EN 5.0 - 07/2009
C00011
C00012
C00013
C00015
C00016
Parameter | Name:
C00011 | Appl.: Reference speed
Data type: UNSIGNED_16
Index: 24564
d
= 5FF4
h
Setting of the reference speed
• In the controller, all speed-related signals are processed to one reference variable in percent.
• Set a reference speed here that corresponds to 100 %.
Note:
This is not a maximum limitation!
All values in percent in the controller may be in the range of 0 ... 199.99 %.
Setting range (min. value | unit | max. value) Lenze setting
50 rpm 9999 1500 rpm
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00012 | Accel. time - main setpoint
Data type: UNSIGNED_32
Index: 24563
d
= 5FF3
h
FB L_NSet_1: Acceleration time of the ramp generator for the main speed setpoint
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 2.0 s
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C00013 | Decel. time - main setpoint
Data type: UNSIGNED_32
Index: 24562
d
= 5FF2
h
FB L_NSet_1: Deceleration time of the ramp generator for the main speed setpoint
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 2.0 s
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C00015 | VFC: V/f base frequency
Data type: UNSIGNED_16
Index: 24560
d
= 5FF0
h
V/f base frequency for VFCplus operating mode
• The motor voltage increases linearly with the frequency until the base frequency is reached. From this value on,
the motor voltage remains constant, the speed increases and the maximum torque decreases.
• After the motor to be used has been selected from the motor catalogue, the suitable value can be entered auto-
matically. An automatic detection via the motor parameter identification is possible as well.
Setting range (min. value | unit | max. value) Lenze setting
7.5 Hz 999.9 50.0 Hz
; Read access ; Write access CINH PLC STOP No transfer COM ; MOT Scaling factor: 10
Parameter | Name:
C00016 | VFC: Vmin boost
Data type: UNSIGNED_16
Index: 24559
d
= 5FEF
h
Boost of the V/f voltage characteristic within a small speed or frequency range for the VFCplus operating mode
• This may increase the starting torque.
• After the motor to be used has been selected from the motor catalogue, the suitable value can be entered auto-
matically. An automatic detection via the motor parameter identification is possible as well.
Motor control (MCTRL)
: Setting Vmin boost
Setting range (min. value | unit | max. value) Lenze setting
0.0 % 100.0 0.0 %
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
