Lenze L-force 8400 BaseLine D - Main setpoint path

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 147
8400 BaseLine D | Software Manual
Function library
Function blocks
Parameter
9.1.1.1 Main setpoint path
 The signals in the main setpoint path are limited to a value range of ±32767.
 The signal at nNSet_a is first led via the JOG selection function.
 A selected JOG value switches the nNSet_a input inactive. Then, the subsequent signal
conditioning operates with the JOG value.
Identifier/data type
Index
Possible settings INFO
dnTir
DINT
C012
0.0 s 999.9 Acceleration time - main setpoint
Initialisation: 0.0 s
dnTif
DINT
C013
0.0 s 999.9 Deceleration time Tif for the main
setpoint
• Initialisation: 0.0 s
C39/[1...3]
Array of INT
C039/1..3
-199.9 % 199.9 Fixed setpoints (JOG setpoints)
• Initialisation: 0.0 %
bSShapeActive
BOOL
C134
Activates S-shaped ramp function
generator characteristic for the main
setpoint
• The time constant is set using
nTiSShaped.
• Initialisation: 0 (deactivated)
0 S-shaped ramp function generator
characteristic deactivated
1 S-shaped ramp function generator
characteristic activated
nTiSShaped
INT
C182
0.0 s 50.0 Ti time of the S-shaped ramp
function generator
• Initialisation: 20.0 s
