5.1.1.1 Parameter setting of the V/f characteristic control
Overview of the relevant parameters
 How to parameterise the V/f characteristic:
1. Select the operating mode " V/f characteristic control" with appropriate
characteristic shape C006
.
2. When using an asynchronous motor which deviates from the standard motor,
having a different rated frequency than 50 Hz (star) / 87 Hz (delta) and a different
number of pole pairs than 2:
• Enter nameplate data of the motor (at least rated speed, rated frequency and
rated voltage)
3. If required, adapt the base frequency of the V/f characteristic C015
4. If required, rise the V/f characteristic by V
min
C016
See also: Setting the V/f base frequency ( 77)
Setting V
min
boost ( 78)
Parameter INFO
C006
Selection of the operating mode for V/f characteristic control without
feedback with
• value "6" for linear characteristic or
• value "8" for quadratic characteristic
C011
Reference speed
C015
Base frequency
C016
V
min
boost
C018
Switching frequency
C021
Slip compensation
C022
Current limit (in motor mode)
C023
Current limit (in generator mode)
C073
I
max
current controller gain
C074
Reset time I
max
current controller
C909/1 /2
Maximum positive / negative speed
C910/1 /2
Maximum positive / negative output frequency
