8400 BaseLine D | Software Manual
Drive control (DCTRL)
Device states
52 L Firmware 03.00 - DMS EN 5.0 - 07/2009
4.1.8 "Trouble" state
This device state becomes active as soon as a monitoring mode responds for which the
"Trouble" error response has been parameterised.
The motor has no torque (is coasting) due to the inhibit of the inverter.
The "Trouble" device state is left automatically as soon as the error cause is eliminated.
Depending on certain conditions, the "Trouble" device state changes to another state:
LED DRIVE READY LED DRIVE ERROR Display in C00137
OFF Trouble
State no. State name Condition(s) for the state change
11 ReadyToSwitchON This state is accepted automatically without evaluating a
control bit
12 OperationEnabled Control bit "ControllerInhibit" of all control channels = FALSE
& the message has been cancelled again
13 SwitchedON Control bit "ControllerInhibit" of a control channel = TRUE
& the message has been cancelled again
14 TroubleQSP There is an error in the system configured to "TroubleQSP"
& the message has been cancelled again
