Lenze L-force 8400 BaseLine D - Page 207

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 207
8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00581
C00581
C00598
C00600
C00601
Parameter | Name:
C00581 | Resp. LS_SetError_x
Data type: UNSIGNED_8
Index: 23994
d
= 5DBA
h
SB LS_SetError_1: Selection of the error responses for application error messages
• An application error message is tripped by a FALSE-TRUE edge at the binary inputs bSetError1...2.
Selection list
0 No Reaction
1Fault
2Trouble
4 WarningLocked
Subcodes Lenze setting Info
C00581/1 1: Fault Resp. LS_SetError_1 bSetError1
C00581/2 1: Fault Resp. LS_SetError_1 bSetError2
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00598 | Resp. to open circuit AINx
Data type: UNSIGNED_8
Index: 23977
d
= 5DA9
h
Configuration of monitoring of the analog input
Selection list
0 No Reaction
1Fault
2Trouble
4 WarningLocked
Subcodes Lenze setting Info
C00598/1 1: Fault Response to open circuit at AIN1 when being configured
as 4 ... 20 mA current loop
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00600 | Resp. to DC bus overvoltage
Data type: UNSIGNED_8
Index: 23975
d
= 5DA7
h
Configuration of monitoring of the motor control (group 3)
Selection list
1Fault
2Trouble
Subcodes Lenze setting Info
C00600/1 2: Trouble Resp. to undervoltage in the DC bus
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00601 | Del. resp.to fault: DC bus overvoltage
Data type: UNSIGNED_16
Index: 23974
d
= 5DA6
h
Delay times for error responses
Setting range (min. value | unit | max. value)
0.00 s 65.00
Subcodes Lenze setting Info
C00601/1 2.00 s Delay time for error activation "DC-bus overvoltage"
• In case of DC-bus overvoltage, an error is only trans-
mitted after this delay time has elapsed.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
